STRAIGHTER CUTS ON LARGER, DIFFICULT TO CUT MATERIALS
Unique gullet design for increased beam strength

OPTIMUM CHIP FORMATION IN WORK HARDENING ALLOYS
Precision ground teeth—smoother tooth face and gullet surfaces
Patented special set and tooth profile

IMPROVED LIFE WITH OPTIONAL M-51 EDGE MATERIAL
Increased heat and wear resistance
Available as listed below

Download SDS

SPECIFICATIONS

WIDTH X THICKNESS		TPI
IN	MM	0.7/1.0	1.0/1.3	1.4/2.0	2/3	3/4	4/6
1 x .035	27 x 0.90
1-1/4 x .042	34 x 1.07
1-1/2 x .050	41 x 1.27
2 x .050	54 x 1.27
2 x .063	54 x 1.60
2-5/8 x .063	67 x 1.60
3 x .063	80 x 1.60
= Milled tooth = Ground tooth = Available with M-51 edge

WARRANTY
LENOX warrants to the original owner that its products are free from defects in material and workmanship for the following periods from the date of the original purchase: Hand Tools are warranted for the anticipated life of the tool; torches and torch accessories are warranted for three years. Please provide proof of date of purchase when making claim. All other products are covered under our manufacturer’s warranty which guarantees the products to be free from defects in material and workmanship for a period of 90 days. This warranty does not apply to product that has been damaged as a result of improper maintenance, accident or other misuse, or which fails to operate due to normal wear and tear. This warranty is void if the product is repaired or modified in any way by anyone other than LENOX. LENOX makes no other warranties, express or implied, concerning the product or the merchantability or fitness thereof for any purpose. In no event shall LENOX be liable for incidental or consequential damages.
